Scotch Yoke Actuator

Product Introduction

9TORC Pneumatic Scotch Yoke Actuator is designed to provide high torque output for quarter-turn valve automation applications. The Scotch Yoke mechanism converts linear piston movement into rotary motion, producing a torque profile suitable for operating industrial valves.

Its compact construction, robust mechanism and high torque output make it suitable for demanding valve automation applications across industrial process systems.

Key Specifications

Actuation Type: Pneumatic Scotch Yoke
Output Torque: Up to 5,00,000 Nm
Operating Pressure: 3 to 8 bar
Rotation: 90° / 120° / 180°
Double Acting / Spring Return: Yes
Mounting Standard: ISO 5211 / Customized
Construction: Heavy-duty industrial design

Construction & Design

The Scotch Yoke mechanism is engineered to efficiently convert pneumatic piston movement into rotary output. The actuator can be configured for different valve torque requirements and operating conditions.
